DC 12V Variable Speed Worm Gear Reducer Motor, RV40 120W 50K High Torque Adjustable Reversible Electric Worm Geared Reduction Motor, with Self-Locking Function, 0.71in Output Bore

DescriptionThis worm gearbox features high efficiency and a self-locking function. Its gapless structure means free maintenance and prevents the lubricant from being easily lost. The pure copper motor allows for low-noise and powerful working, making it suitable for packaging & vending machines, textile&printing & food machinery, office equipment, etc.DetailsPower Cable: The power cable uses pure copper coils, featuring good conductivity and a large current carrying capacity.Cap: The yellow cap can effectively protect the output bore when not in use. After removing it, you can insert the shaft in the hole.SpecificationsType: DM09Model: NLRVGearbox: NLRV-040Color: GrayMaterial: Cast Aluminum, Hollow Steel TubeProcesses: Die-casting, Heat TreatmentShape: Square, RoundType: DC MotorGearbox Type: Worm GearboxMotor: Pure Copper MotorNoise: About 50-60dbOutput Type: Hollow BoreTorque: 36NMVoltage: DC 12VPower: 120WSpeed: 1800RPMAMP: 14ARatio: 1:50(50K)Input/Output Flange Size: 9x9cm(3.54x3.54inch)Output Bore Diameter: 18mm(0.71inch)Installation Hole: 7mm(0.28inch)Gear Motor Size(LxH): 9x14cm(3.54x5.51inch)Connect Interface Size: 9x9cm(3.54x3.54inch)Net Weight: 5kg(11.02lb)Package Includes1x 120W Gear MotorNote1.It is not suitable for positioning applications. Please note that the product does not include a speed controller.2.To meet the different needs of customers, our motor does not include a power cord. You need to purchase a power cord to connect.The motor can run for a long time within the safe speed regulation range. The safety speed range of a small load: is 50% of full speed-full speed; The safety speed range of a large load: is 70% of full speed-full speed.

• 【Wide Applications】- Hysinwier Variable worm gear reducer is a capable helper in industrial applications and a variety of machines. It can be widely used in CNC equipment, mechanical equipment, milling machines, printing machinery, production workshops, assembly lines, office equipment, logistics equipment, etc.
• 【Built to Last】- This variable speed worm motor is mainly superior cast aluminum alloy and steel with heat treatment and die-casting process, making it have high rust resistance, impact resistance and heat resistance; The slow start function and self-locking function(clockwise/counterclockwise self-locking) ensure your safety during use.
• 【Stable & Efficient Running】- This variable speed worm gear motor adopts a single-phase pure copper motor with 120W power, 1800RPM speed and 50K(1:50) reduction ratio to ensure stable output and achieve efficient running; Both ends of the rotor are designed with ball bearings, which reduce friction and temperature during use. Low noise, fast heat dissipation.
• 【Adjustable Speed & Reversing Function】- You can match this worm gearbox reducer motor with a speed controller(Not included), to adjust different speeds according to your needs and to achieve a desired effect; It has a reversing function, which is flexible with normally open and closed control systems.
• 【Thoughtful Design】- The yellow cap can effectively protect the output bore when not in use; Its gapless structure means free maintenance and prevents the lubricant from being easily lost. 【Note】To meet the different needs of customers, our motor does not include a power cord.
